50W Raycus QB Fiber Laser Marking Machine Engraver Support Lightburn Rotary US
Description
PS:
The Voltage of the machine have AC110V and AC220V.Please give me message to tell me which voltage you need .Or we will ship the package as the voltage in your country.
| Technical Parameters | |
| Item | Value |
| Application | Laser Marking |
| Laser Power | 50W |
| Brand Of Fiber Laser Module | Raycus |
| Lift Span Of Fiber Laser Module | 100,000 hours |
| Light Beam Quality | M2<1.5 |
| Marking Line Speed | ≤8000mm/s |
| Minimum Line Width | 0.012mm |
| Minimum Character | 0.15mm/Depends on the material |
| Marking Depth | ≤1.2mm/Adjustable depends on the materials |
| Repeating Precision | ±0.003mm |
| Focus Spot Diameter | <0.01mm |
| Output Power Of Laser | 10%~100% continuously to be adjusted |
| Laser Wavelength | 1064nm |
| Power Supply | AC220V/50Hz |
| Temperature /Humidity | 15℃~35℃/10%~95% |
| Power Consumption | ≤400W |
| Operating System | Win XP/Win7/Win8/Win10 |
| Marking Format | Graphics,AI,Text, PLT, DXF, BMP, Dst, Dwg, LAS, DXP,Bar code, QR code etc. |
| Laser Type | Fiber Laser |
| Condition | New |
| Cooling System | Inbuilt air cooling |
| Communication | Standard USB2.0 |
| Control Software | Ezcad (Easy To Use) |
| Place of Origin | China |
| Certification | CE, ISO |
| Laser Source Brand | Raycus |
| Control System Brand | BJJCZ (Original version) |
| Gross Weight (KG) | 55KG |
| Net Weight (KG) | 45KG |
| Package | Wooden box |
| Key Selling Points | Easy to operate |
| Rotary Axis | Optional |
| After Warranty Service | Video technical support, Online support, Spare parts |
| Marking Area | 300mm*300mm |
| Machinery Test Report | Provided |
| Video Outgoing-Inspection | Provided |
| Warranty of core components | 2 years |
| Core Components | Motor, bearing, gear, pump, laser source, lens, galvanometer, control board |
| Optional (Not For Free) | Rotary device,moving table,other customized automation |
| This above parameters are laboratory test results,subject to actual operating conditions. | |
50W Raycus QB Fiber Laser Marking Machine Engraver Support Lightburn Rotary US
$2,999.00
